Name: Mainboard MSI MAG Z790 TOMAHAWK MAX WIFI DDR5
Brand: MSI
SKU: 1690
Price: 8499000 VND
Availability: InStock
Rating: 3 (885 reviews)

Mainboard MSI MAG Z790 TOMAHAWK MAX WIFI DDR5

Mã SP: SP1690

3 đánh giá Lượt xem: 885

Socket: LGA 1700 Hỗ trợ Intel thế hệ thứ 14, 12,13, Intel® Pentium® Gold and Celeron® Processors

Kích thước: ATX

Khe cắm RAM: 4 khe (Tối đa 192GB)

Khe cắm mở rộng: 2x PCI-E x16 slot, 1x PCI-E x1 slot

Khe cắm ổ cứng: 4x M.2, 8x SATA 6G

Giá niêm yết: ~~9,999,000 đ~~

Giá khuyến mại:

8,499,000 đ [Giá đã có VAT]

Tuỳ chọn thuộc tính

Mainboard MSI MAG Z790 TOMAHAWK MAX WIFI DDR5

8,499,000 đ

Mô tả

Sản phẩm Bo mạch chủ

Tên Hãng MSI

Model MAG Z790 TOMAHAWK MAX WIFI DDR5

CPU hỗ trợ Intel

Chipset INTEL Z790

RAM hỗ trợ 4x DDR5 UDIMM, Maximum Memory Capacity 192GB Memory Support 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC) 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC) 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz

Khe cắm mở rộng 2x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)

Ổ cứng hỗ trợ 4x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280/2260 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices 8x SATA 6G *PCI_E1 slot will be Gen5x8 when installing M.2 SSD in the M2_1 slot. *SATA_1 & SATA_2 will be unavailable when installing M.2 SATA SSD in the M2_3 slot.

Cổng kết nối (Internal) 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 6x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x TBT connector (JTBT, supports RTD3) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports 1x USB 3.2 Gen2 Type C ports 1x USB4 card connector (JTBT_U4_1, supports RTD3)

BACK PANEL Display Port USB 3.2 Gen 1 5 Gbps (Type-A) USB 3.2 Gen 2 10Gbps (Type-A) 2.5G LAN Wi-Fi / Bluetooth Audio Connectors HDMI™ Clear CMOS Flash BIOS USB 3.2 Gen 2 10Gbps (Type-A) USB 3.2 Gen 2 10Gbps (Type-C) USB 3.2 Gen 2x2 20Gbps (Type-C)

LAN / Wireless Intel® 2.5Gbps LAN Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth®5.4**, MLO, 4KQAM

Kích cỡ ATX 243.84mmx304.8mm

Mainboard MSI MAG Z790 TOMAHAWK MAX WIFI DDR5
